GIGS Emergency Gate

WHAT IS A GIGS EMERGENCY GATE?

The GIGS Emergency Gate is a wide aperture gate. It seamlessly incorporates into the GIGS barrier system. The robust unit allows event organizers to securely provide event attendees and emergency responders rapid access and egress to event spaces.

If there are many visitors, our GIGS emergency gate also guarantees fast evacuation or care of the visitors. The Panic Gate, also known as Emergency Exit or Emergency Gate, is used as a visible marker for escape routes at festivals, concerts, and other major events.

Verifiably pressure-stable, our escape gate has a static certificate. The green swing doors of the escape gate comply with the European standards for emergency exits. In addition, you can open our emergency gate with one hand, even under the strongest counter pressure. You cannot reach the opening bolt from the public side. This also makes it ideal as an emergency exit in the breakwater. There is a step at the other side of the gates, which also facilitates the access and view to the visitors.

GET IN TOUCH

Technical Data

Material

aluminum

Dimensions (l x w x h)

2.135 x 1.25 x 1.18 m (84 x 49 x 46 in)
Width passage: 1.20 m (47 in)

Weight

approx. 102 kg (225 lbs)

Color

silver or black/green

Additional Information

Combined with other GIGS elements, these emergency exit gates are an ideal add-on for events with high attendance and when fast evacuation is required. Doors open both directions.

Transport

5 per dolly

PRODUCT FEATURES FOR GIGS EMERGENCY GATE

The wide aperture Emergency Gate connects seamlessly and securely to GIGS barrier lines using the eps double bolt system. An integrated locking mechanism enables security and event staff swift, effective control. We designed and built this system at eps’s Italian manufacturing division. The Emergency Gate is constructed to CE Standard.

You can combine our GIGS emergency gate with all other elements of the GIGS series. It is available in two versions; galvanized steel or aluminum. Both have refractory properties, a depth of 1.25 meters (49 in) and a height of approximately 1.18 meters (46 in). At 2.18 meters, the steel door is slightly wider than the aluminum door.

The passage widths also vary. In the steel version, the passage width is 1.20 meters (47 in). In the aluminum emergency gate, the width is 1.36 meters (54 in). The galvanized steel door weighs around 224.5 kilograms (495 lbs), while the lighter aluminum emergency gate weighs 102 kilograms (225 lbs). The two versions also differ in color. The steel door is available in black-green. The GIGS emergency gate of aluminum is available in silver-green.
