ARMORDECK 1

A turf Protection System for Stable Event Floors

The ArmorDeck 1 pedestrian flooring offers superior protection for sports pitches and running tracks. The system is quick to deploy and provides high levels of protection for sensitive surfaces, such as natural turf. Thanks to the unique design, the grass is kept intact longer.

HIGHLIGHTS

  • Permits light, air, and water to reach the subsurface
  • Proprietary technology allows for drainage without compromising unparalleled liquid-spill protection
  • Pedestrian-friendly
North & South America
Australia
Europe
The Product you are looking for is not available? Don't worry, check all eps products worldwide and get in touch. Let us find the perfect alternative for you.
Sensitive Ground Protection Sensitive Ground Protection
Stadium Turf and Running Tracks Stadium Turf and Running Tracks
Temporary Event Spaces Temporary Event Spaces
Tennis Courts Tennis Courts
CURIOUS?

Special ground issues, difficult terrain? No problem. Our team has got the right solution for all your needs.

PRODUCT FEATURES FOR ARMORDECK 1

ArmorDeck 1 event flooring has a sandblasted, non-slip surface with a flat studded profile. The unique connection system ensures high strength and stability. Moreover, these mechanisms minimize damage to or compaction of the subsurface. They also allow sufficient light, water, and air to reach covered lawns. Thanks to special channels located at the joints of the overlapping panels, they provide the best protection against spills.

Product Description arrow down

The system is made of high-density polyethylene. Therefore, the turf protection panels have high impact resistance and rigidity. Besides, the robust and UV-resistant plastic provides the panels with an exceptionally long service life so that you can use them for several years for temporary events. In addition, the robust and UV-resistant plastic equips the panels with remarkable durability so they can be used for temporary events for several years.

Non-slip surface structure

One panel measures around 1.15 by 1.15 meters (45 by 45 inches). The cover dimension is around 8 centimeters (3 inches) less on each side. The height is 5 centimeters (2 inches). Moreover, it weighs 14.10 kilograms (43 lbs). ArmorDeck 1 also features a slightly ribbed and, thus, non-slip surface structure. It is available in transparent, light, or anthracite grey. Other color variants are also available on request.

Light and Oxygen For Lawns

The sophisticated connection system keeps panels in place and the event areas free of tripping hazards. Thanks to special openings and channels, the covered lawns continue to be supplied with light and oxygen. Moreover, the system drains large quantities of water or spilled liquids.

Technical Data arrow down
Technical Data
Material
Hardened polythene with UV stabilizer
Dimensions (l x w x h)
External dimensions: approx. 115 × 115 cm (46 × 46 in), H = approx. 5 cm (2 in)
Cover dimension: approx. 107 × 107 cm (43 × 43 in) = 1,14 m² (12.27 ft²)
Weight
Approx. 14.10 kg (43 lbs) / element
Transport
22 pallets à 40 elements per standard trailer
Approx. 1,003 m² (10,795 ft²)
Optional Extras arrow down

Besides the associated keys for the cam locks, we offer several extensions. These include flattened ramps specially adapted to the system so you can achieve smooth and safe transitions from the substrate to the installed floor covering. Wheelchair users or visitors with walking aids or pushchairs can effortlessly access the event area.

Easily Combine with Other Systems

The range also includes components that serve as expansion joints. These compensate for the expansion of the panels at high temperatures. A further option is a combination with floor protection systems suitable for heavy loads; for example, ArmorDeck 3 as an ideal solution. Depending on your application, this makes it easy to create highly stable event areas that are also pedestrian-friendly.

EXTENSIONS AT A GLANCE

  • Ramp accessories ensure safe and smooth transitions to the subsurface
  • Optional range of underlays to protect the subsurface that can adapt to varying ground conditions
  • Transition products seamlessly connect the panels with other ground and turf protection systems
  • ArmorDeck 3, a heavy-duty, drivable turf protection system, can be combined with ArmorDeck 1 to provide visually appealing event spaces
  • CAD design to help optimize planning processes

BEST PRACTICE

ArmorDeck 1 offers superior protection for sports pitches, here at concerts from Adele and Ed Sheeran

ARMORDECK 1: DID YOU KNOW?

Those who choose ArmorDeck 1 will receive durable pedestrian event flooring. Moreover, this flooring is quick and easy to install. You can also disassemble this in no time. It is easy to clean.

Space-saving and cost-effective

Besides, transport and storage are highly efficient: You can stack the panels very flat. So, you can store and transport in a space-saving and cost-effective manner.

Advantages and Benefits arrow down
  • Permits light, water, and air to reach the subsurface
  • Proprietary technology allows for drainage without compromising unparalleled liquid-spill protection
  • Pedestrian-friendly
  • Even weight distribution of loads protects the subsurface and reduces compression
  • Suitable for indoor and outdoor use
  • Optimal performance on flat surfaces and natural turf
Application Details arrow down

On even ground, ArmorDeck 1 proves to be a pedestrian-friendly turf protection system ideal for natural green areas. This system is perfect for a football stadium’s natural grass pitch, a golf course’s turf, or a tent floor. Moreover, it is ideal for concerts, festivals, or other temporary events involving sensitive lawns with gentle and robust floor covering.

For a Safe and Seamless Event Area

The load-bearing turf protection can easily withstand large crowds of spectators. This makes ArmorDeck 1 ideal for creating a safe and seamless event area in the audience zone of crowded major events.
