GIGS STRAIGHT

Fundamental Element for Pressure-Stable and Flexible Barricade Lines

GIGS Straight is a fundamental element for creating pressure-stable and flexible barricade lines to ensure crowd security and safety. These high-quality stage barricades are designed for large events with high crowd loading, making them ideal for stages, delays, FOH (Front of House), high-density crowd splits, and golden circles. They are also suitable for various crowd management systems and offer a wide range of application possibilities. With GIGS Straight, you can professionally block off stages, FOHs, delay towers, and separate event areas such as VIP areas or Golden Circles, as well as create safe access routes for security staff and emergency services.

HIGHLIGHTS

Trusted and utilized by the biggest productions across the globe
The secure fundamental element for the modular GIGS barricade range
Certified load-bearing to 5 KN/m

Product availability in your region

Find out about the availability of this product in your region:

USA
Canada
Brazil
Australia
New Zealand
UK
Ireland
Denmark
Sweden
Finland
Norway
Italy
Poland
Germany
Austria
Switzerland

Not available in your region? Contact us now and we will find an alternative for you.

Stadium and Arena Shows

Festivals

Walkways

Catwalks

Sporting Events

Heavy-Duty Crowd Control Solutions

PRODUCT FEATURES FOR GIGS STRAIGHT

The GIGS Straight units serve as the sturdy foundation of the GIGS barricade system. You can combine these double-bolted units with GIGS emergency gates and specialized elements to accommodate elaborate stage configurations and cable runs. The GIGS system is designed and built at eps’ Italian manufacturing division and is constructed according to CE Standards. Additionally, every batch of the GIGS system undergoes rigorous testing to ensure its quality and reliability.

Product Description

The GIGS Straight system is made from lightweight aluminum, providing highly static pressure stability. However, we recommend additional lining for optimal performance if the surface is uneven. The fireproof GIGS Straight is available in silver and black and comes in two versions.

Lightweight Version

The standard version of GIGS Straight weighs around 41 kilograms (90.40 pounds) and has a width of 1.09 meters (43 inches) and a depth of 1.25 meters (49 inches). The other version is narrower, measuring only 0.54 meters (21 inches) wide and weighing around 21 kilograms (46.20 pounds). The narrow version only has a stabilizing diagonal on the back, while the wider version has two struts and a practical step.

Combinable With All GIGS Components

Both versions of GIGS Straight are approximately 1.18 meters (46 inches) high and serve as a stable foundation for a modular barricade system. Therefore, you can combine the element with all GIGS components in various ways to create customized configurations. For example, the GIGS Bar Top can be added to transform the GIGS Straight into a stable bar shelf.

Technical Data

Material

Aluminum

Dimensions (l x w x h)

Standard: 1.09 × 1.25 × 1.18 m (43 × 49 × 46 in)
Half Standard: 0.54 × 1.25 × 1.18 m (21 × 49 × 46 in)
Tread: 0.75 m (30 in)

Weight

Standard: 41 kg (90.4 lbs)
Half Standard: 21 kg (46.2 lbs)

Color

Silver (aluminum) or Black

Accessories

Vario corners that flex - / + 60°, fixed outward/inward corners in 5° - 90°, elements for multicore cable runs, access gate units in various sizes, bar counters

Transport

20 resp. 10 standard units per transport rack
Approx. 36 transport racks per standard trailer
(Approx. 390 m / 1,280 ft overall length)

Optional Extras

GIGS Back Step – raised security walkway
GIGS Sight Kill – height extensions for increased privacy and security
GIGS High Fence – height extensions for increased security with full visibility
GIGS Bar Top – fast to install, stable, and multiple-use countertop
Cable Protectors to safeguard equipment and audiences on the event floor
CAD design to help optimize the planning process

BEST PRACTICE

The GIGS Straight provides the basis for individual barrier solutions and safe events, such as here at the “Rock am Ring” festival

GIGS STRAIGHT: DID YOU KNOW?

If you need to manage crowds at a high-density event, the GIGS Straight system is an ideal solution. It can effectively separate spaces and provide clear visibility for security personnel to monitor everyone in the crowd.

Advantages and Benefits

Trusted and utilized by the biggest productions across the globe
The secure basis for the modular GIGS barricade range
Certified load-bearing to 5 KN/m
Optimal transport efficiency
100 % recyclable materials

Application Details

The high-quality stage barricades are designed with reinforced diagonally running struts at the rear, ensuring durability and stability. These solid barricade elements are suitable for large events with high crowd pressure and protect spectators, stars, and event staff. They are commonly used for front-of-stage barrier lines at festivals and stadiums and stabilize the GIGS Line-up Gates.

Allows Employees to Intervene Immediately

In addition, the GIGS Back Step on the back of the stage barricades allows employees to maintain visibility of the event guests and intervene immediately if necessary. For further protection, we offer GIGS High Fences made from impact-resistant, transparent polycarbonate, which can be attached to the GIGS Straight barricade system.
